Level Transmitters

Level Transmitters

The AKS 4100 / AKS 4100U liquid level sensor is designed specifically to measure refrigerant liquid levels in a wide range of refrigeration applications, in vessels, accumulators, receivers, standpipe...

Avail from us, superior quality Liquid Level Transmitter, which is used for continuous level indication and control for any liquid that is chemically compatible with its wetted parts. Our range of Liquid Level Transmitters is duly checked on different parameters at each level of production process in order to deliver a flawless range of Liquid Level Transmitter to the clients.

Beatures and Benefits
Top mounted type and is used for continuous level indication.
Resistance/ Reed switch Contact Chain, Max. 3 Mtr Length.
4-20 mA O/P-2, 3 or 4 wire /0-10 VDC output or as required.
3 " NB MS flange drilled to ASA 150# as standard and other connection on demand.
Accuracy : 1 cm, 90 Deg C max Temperature, 20 Bar max Pressure.
SS 304/316/PVC/PP/PTFE Guide Tube & Float.
Adjustable Multiple Alarm Contacts on Electronic Controller.
IP56/IP65/Ex-Proof Gr IIA & IIB approved enclosure.
Top Mounting with 80 NB Flanged Connection.
Customized Length up to 3 Mtrs.


  • Tanks of Oils
  • Fuels
  • Chemicals
  • Pure/Industrial water
  • Ship/LPG tanks
  • Critical Inventory
  • Pharmaceutical plant
